- PTZ Locked
- Yes
- IVS (Perimeter Protection)
- Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification
- Face Detection
- Supports face detection, snapshot, and face enhancement; Supports face cutout: Face, one-inch photo; Capturing strategies include real-time capturing and quality first
- People Counting
- Supports counting the number of people that cross the detection line, counting the number of people in an area and queue management. Also, only people counting that cross the detection line supports the report function.
- SMD
- Yes
- Light Warning
- White light warning; Flash duration: 5 s–30 s; Flash frequency: high, medium, low
- Sound Warning
- Offers 16 sound alarms and supports importing custom sound alarms; Sound: high, medium, low; Play times: 1-10
- Video Compression
- H.264H;H.264B;Smart H.265+;H.264;H.265;MJPEG(Sub Stream);Smart H.264+
- Streaming Capability
- 3 streams
- Resolution
- 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
- Video Frame Rate
- Main stream: 4M/3M/1080P/1.3M/720P@(1-25/30 fps) Sub stream 1: D1/VGA/CIF@(1-25/30 fps) Sub stream 2: 720P@(1-25/30 fps)
- Bit Rate Control
- CBR/VBR
- Video Bit Rate
- H264: 96 Kbps–14,848 Kbps H265: 38 Kbps–8,960 Kbps
- Day/Night
- ICR: Color; B/W; Auto; Electronic: Color; B/W; Auto
- BLC
- Yes
- WDR
- 120 dB
- HLC
- Yes
- White Balance
- Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
- Gain Control
- Auto; manual; gain prio
- Noise Reduction
- 2D NR; 3D NR
- Motion Detection
- Yes
- Region of Interest (RoI)
- Yes
- Image Stabilization
- Electronic Image Stabilization (EIS)
- Defog
- Electronic
- Digital Zoom
- 16×
- Image Rotation
- 180°
- Privacy Mask
- Up to 24 areas can be set, with up to 8 areas in the same view; 8 colors available
- Audio Compression
- PCM; G.711A; G.711MU; G.726; MPEG2-Layer2; G.722.1
- Network Port
- RJ-45 (10/100 Base-T)
- Wi-Fi
- Yes
- Wi-Fi Standard
- IEEE802.11b;IEEE802.11g;IEEE802.11n;IEEE802.11ax
- Wi-Fi Frequency Range
- 2.4 GHz
- Wi-Fi Transmission Rate
- 229 Mbps
- Max Transmission Power
- ≤20 dBm@2400–2483.5 MHz
- Network Protocol
- FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;802.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IGMP;HTTP;SSL;DHCP;SMTP;Qos;RTSP;ARP
- Interoperability
- CGI;SDK;ONVIF (Profile S&G&T)
- User/Host
- 20 (total bandwidth: 64 M)
- Storage
- Micro SD card (512 GB); FTP/SFTP; NAS
- Browser
- IE 9 and later versions; Chrome 41 and later versions; Firefox 52 and later versions; Safari 10 and later versions
- Management Software
- DMSS;DSS Pro
- Mobile Client
- iOS;Android
- Certifications
- CE-EMC: EN 55032; EN 61000-3-3; EN 61000-3-2; EN 50130-4; EN 55035 CE-LVD: EN 62368-1 CE-RED:EN301489; EN300328; EN IEC 62311
- Audio Input
- 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive))
- Audio Output
- 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive))
- Alarm Linkage
- Capture; recording; send email; preset; tour
- Alarm Event
- Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
- Audio I/O
- 1/1
- Power Supply
- 12 VDC, 2 A ± 10%
- Power Consumption
- Basic: 4 W; Max: 13 W (illuminator + warning light on)
- Operating Temperature
- –30 °C to +60 °C (–22 °F to +140 °F)
- Operating Humidity
- ≤ 95%
- Protection
- TVS 6000 V lightning proof;IP66;IK08; surge protection; voltage transient protection
- Product Dimensions
- 65.7 mm × Φ128.0 mm (2.59" × 5.04")
