- Flusso Principale
- 50 Hz:
25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) - Flusso Secondario
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) - Terzo Flusso
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Il terzo flusso è supportato con determinate impostazioni. - Compressione Video
- Flusso principale: H.265/H.264/H.264+/H.265+,
Flusso secondario: H.265/H.264/MJPEG,
Terzo flusso: H.265/H.264,
*Il terzo flusso è supportato con determinate impostazioni. - Bit Rate Video
- 32 Kbps a 16 Mbps
- Tipo H.264
- Baseline Profile, Main Profile, High Profile
- Tipo H.265
- Main Profile
- Controllo Bit Rate
- CBR, VBR
- Scalable Video Coding (SVC)
- Codifica H.264 e H.265
- Region of Interest (ROI)
- 1 regione fissa per flusso principale e flusso secondario
- Main Stream
- 50 Hz:
25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) - Sub-Stream
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) - Third Stream
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings. - Video Compression
- Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
*Third stream is supported under certain settings. - Video Bit Rate
- 32 Kbps to 16 Mbps
- H.264 Type
- Baseline Profile,Main Profile,High Profile
- H.265 Type
- Main Profile
- Bit Rate Control
- CBR,VBR
- Scalable Video Coding (SVC)
- H.264 and H.265 encoding
- Region of Interest (ROI)
- 1 fixed region for main stream and sub-stream
